PSU Connectors Explained: 24-Pin, EPS, PCIe, and 12VHPWR

PSU connectors are the cable ends a power supply uses to deliver regulated DC voltage to the motherboard, processor, graphics card, drives, and peripherals. Each connector has a fixed pin count, a defined voltage set, and a current rating, and each powers a specific part of the system. A modern unit ships with the 24-pin ATX connector for the motherboard, the 4+4 EPS connector for the processor, the 6+2 PCIe connector for the graphics card, the SATA connector for drives, the Molex connector for legacy devices, and the 16-pin 12V-2×6 connector (which replaced 12VHPWR) for high-power graphics cards.

What Are PSU Connectors?

PSU connectors are the standardized cable terminals through which a power supply delivers its regulated 3.3-volt, 5-volt, and 12-volt outputs to each component:

• Conversion to delivery: the unit converts wall AC into DC rails, and the connectors carry those rails over dedicated cables to the parts that need them.
• Fixed layout: each connector type has a set pin arrangement, a defined voltage-and-ground map, and a current rating that caps the power it carries safely.
• Component-side is standardized: any unit’s 24-pin cable fits any motherboard, because the end that plugs into a component follows the industry standard. The connectors carry the output of the AC-to-DC conversion process to the components that consume it.

Best for understanding: the six connector families below cover every cable a desktop power supply provides.

What Is the 24-Pin ATX Connector?

The 24-pin ATX connector is the main motherboard power connector, delivering 3.3-volt, 5-volt, and 12-volt power to the board and its onboard components:

• What it feeds: the motherboard voltage regulators, the chipset, the memory, the PCIe slots, and the onboard controllers.
• 20+4 split: it separates into a 20-pin and a 4-pin section to serve older 20-pin boards, though all current boards use the full 24.
• Rails and signals: several 12V, 5V, and 3.3V pins plus grounds, and the power-on and power-good signal pins that let the board control the unit.
• Always required: it is the single largest connector on the unit, and no system runs without it. The article on how a motherboard distributes power traces where these rails travel.

What Is the EPS CPU Connector?

The EPS connector is the 4+4-pin 12-volt connector that supplies dedicated power to the processor through the motherboard’s CPU voltage regulator:

• Labeled CPU or ATX12V: it delivers 12-volt current straight to the voltage regulator module feeding the processor, separate from the 24-pin.
• 4+4 split: it serves as a single 4-pin connector for low-power boards or a full 8-pin for standard boards.
• Dual on high-end boards: an 8+4 or dual-8 arrangement supplies the higher current a high-core-count or overclocked processor draws.
• Per-connector budget: a single 8-pin EPS carries up to about 235 to 300 watts depending on cable gauge , enough for most processors.

Best for: populate every EPS connector the board provides when running a high-end or overclocked processor, and seat each fully , the CPU draws heavy current and a partial connection generates heat.

What Is the PCIe Power Connector?

The PCIe power connector is the 6+2-pin connector that supplies supplementary 12-volt power to a graphics card beyond the 75 watts the slot provides:

• Slot baseline: the PCIe expansion slot delivers up to 75 watts; a card drawing more pulls direct power from the unit through one or more PCIe connectors.
• 6-pin vs 8-pin: the 6-pin section is rated for 75 watts; the extra 2-pin section upgrades it to an 8-pin rated for 150 watts.
• Scaling with draw: a 225-watt card uses two 8-pin connectors plus the slot; a 300-watt card runs two 8-pin connectors at full draw.
• One cable, two sockets: the splittable 6+2 design serves either a 6-pin or an 8-pin socket on the card. The guide on choosing a graphics card relates connector counts to power draw.

Best for: count the card’s required 8-pin connectors against its total board power , each 8-pin adds 150 watts.

What Is the 12VHPWR and 12V-2×6 Connector?

The 12V-2×6 connector is the current 16-pin GPU power connector that delivers up to 600 watts over a single cable, replacing the earlier, melt-prone 12VHPWR:

• 12VHPWR (ATX 3.0): the original PCI-SIG 16-pin connector , 12 power pins plus 4 sideband sense pins , carried up to 600 watts and debuted on the RTX 4090, replacing multiple 8-pin cables.
• Sense pins: the 4 sense pins report the cable and unit’s capacity to the card, signalling 150, 300, 450, or 600 watts depending on which are grounded.
• 12V-2×6 (ATX 3.1): the revised header keeps the 600-watt class but lengthens the power pins and shortens/recesses the sense pins, so the card only powers up once the power pins are fully seated.
• Same shape: the 12V-2×6 plug is backward compatible with 12VHPWR sockets; a native ATX 3.1 cable is preferred over an adapter for reliable seating.

What Are the SATA and Molex Connectors?

The SATA and Molex connectors are the peripheral power connectors that supply drives, fans, and legacy devices , SATA for modern storage, Molex for older hardware:

• The SATA power connector is a flat 15-pin connector that delivers 3.3-volt, 5-volt, and 12-volt power to SATA solid-state drives, hard drives, and optical drives, and is the standard storage power connector on every current build.
• The Molex connector is an older 4-pin connector that delivers 5-volt and 12-volt power to legacy hard drives, fans, fan controllers, and some accessories, and remains present for backward compatibility.
• The SATA-to-Molex and Molex-to-PCIe adapters convert between connector types but should be used cautiously, because an adapter can exceed a connector’s current rating if it feeds a high-power device.
• The floppy connector, a small 4-pin connector, is a legacy output that some units still include for old peripherals and certain fan controllers.

Best for: SATA daisy-chains several drives per cable; reserve Molex for case fans, fan hubs, and older accessories that predate SATA power.

How Do You Seat PSU Connectors Properly?

You seat a connector properly by pushing it fully into the socket until the retention latch clicks, confirming every pin makes contact before applying power:

• Why it matters: a partial connection makes contact through fewer pins, which raises resistance at the contact and concentrates heat there.
• The click: every keyed connector has a latch or clip that engages at full insertion , the click is the confirmation.
• The 12V-2×6 needs the most care: 600 watts through a compact connector leaves little margin, and early 12VHPWR cables melted when not fully seated or bent sharply near the plug.
• The fix in the connector: the 12V-2×6 revision requires the power pins to seat before the connection registers, so a loose plug stays dark instead of overheating.

Why Should You Not Mix Connectors Between PSU Brands?

Mixing modular cables between brands is dangerous because the end that plugs into the unit’s modular socket is not standardized, so one brand’s cable can route voltage to the wrong pin on another brand’s unit:

• Two different ends: the component end (24-pin, PCIe) is industry-standard, but the modular-socket end is proprietary to each maker and sometimes each model.
• The failure: a mismatched cable can place 12-volt power where the unit expects ground, shorting the connected part and destroying the motherboard, graphics card, or unit.
• The safe rule: use only the cables supplied with that exact unit, or replacement cables the maker verifies for that model. The guide on modular and non-modular power supplies covers the pinout risk in detail.

Best for safety: never assume two brands’ modular cables are interchangeable , even when the plugs physically fit.

PSU Connector Reference Table

The table lists each power supply connector with its pin count, the component it powers, and the typical wattage it carries:

Last Thoughts on PSU Connectors

PSU connectors deliver the unit’s regulated voltages to each part of the system, each with a defined pin count, target, and wattage. The 24-pin ATX powers the motherboard, the 4+4 EPS powers the processor, the 6+2 PCIe adds 150 watts per 8-pin to a graphics card, and the 16-pin 12V-2×6 (which replaced 12VHPWR) carries up to 600 watts to a high-power card over a single cable. SATA and Molex serve drives and legacy devices within their current ratings.

Proper seating until the retention latch clicks prevents the localized heating behind the 12VHPWR melting issue, and modular cables must never be mixed between brands because socket pinouts are not standardized. The computer hardware guide connects these connectors to the rest of the build, and the guide on choosing a power supply explains which connectors a given system requires.

Key Takeaways:

• The 24-pin ATX connector powers the motherboard with 3.3-volt, 5-volt, and 12-volt rails and is always required.
• The 4+4 EPS connector supplies dedicated 12-volt power to the processor, with high-end boards using two connectors.
• The 6+2 PCIe connector adds 150 watts per 8-pin to a graphics card beyond the 75 watts the slot provides.
• The 12VHPWR and 12V-2×6 connector delivers up to 600 watts to a high-power GPU over a single 16-pin cable.
• SATA and Molex connectors power drives and legacy devices, while adapters must stay within their current rating.
• Proper seating until the latch clicks prevents the localized heating behind the 12VHPWR melting issue.
